POWER UP (in exactly this order)

• Console
• Speakers
• UA Interface
• Computer
• Video Monitors
• Indirect Lighting
• +48V Phantom Power to Microphone (from Universal Audio Interface)

CONNECT

• Turn on UAD Meter & Control Panel
• Turn on UAD Console
• Configure MAC System Settings
  • Sound > Output & Input Preferences to “Universal Audio Thunderbolt”
  • Privacy & Security > Microphone > Enable Adobe
• Configure AUDITION
  • Adobe Audtion > Settings > Audio Hardware
  • Device Class: CoreAudio
  • Default Input: System Default – Universal Audio Thunderbolt
  • Default Output: System Default – Universal Audio Thunderbolt
  • Clock: Out: System Default – Universal Audio Thunderbolt

  • I/O Buffer Size: 512 Samples
  • Sample Rate 48000 Hz
• Configure UA INTERFACE
  • UA PREAMP BUTTON toggles between mic and line inputs.  Select MIC CH1.  Use LEVEL KNOB to set mic level.
  • UA MONITOR BUTTON toggles between speaker and headphone outputs.  Use LEVEL KNOB to set output volume.

RECORD (.sesx)

• File > New > Multitrack Session.
  Save to appropriate server bin with standard Philm nomenclature
• Template: None
• Window > Workspace > Default

CLICK TRACK time display (Properties Window)

• Time format: Bars and Beats
• Tempo: 100 beats/minute
• Time Signature: 4/4
• Enable Metronome

TUNING TONE in Track 3: Effects > Generate > Tones

• New Audio Files
• File Name: Tuning Tone
• Sample Rate: 48000
• Channels: Stereo
• Bit Depth: 32 (float).
• Base Frequency: 261.63 Hz (Middle C)

I/O ROUTING → Track 1 Input: [01M] Universal Audio 1

RECORD ARM/ENABLE vocal track.  Then hit RECORD.  Any track which is not record enabled should simultaneously play back in monitor/headphone outputs.

⚠ SAFETY WARNING:  Audio recording engineer controls performer headphone volume level.
